基于 Flask 的 Web API 开发指南

<h1>基于 Flask 的 Web API 开发指<span id="blink">南</span></h1>

李辉（Grey Li） 🐍 PyCon China 2019 上海

---

## 演讲录像

录像暂无。

## 成都站 2.0 版本

- [幻灯片](http://greyli.com/slides/pyconchina2019-api/)
- 录像：[bilibili](https://www.bilibili.com/video/av75168852/) | [YouTube](https://youtu.be/Fz5Zq4WM_c0)

---

## 这本来是一个严肃的演讲

---

## Flask 是什么？

install
```bash
$ pip install flask
```

code (app.py)
```python
from flask import Flask
app = Flask(__name__)

@app.route('/')
def hello():
    return 'Hello, PyCon China!'
```

run
```bash
$ flask run
 ...
 * Running on http://127.0.0.1:5000/ (Press CTRL+C to quit)
```

---

## Web API 是什么？

- 长答案：https://lmgtfy.com/?q=what+is+web+api%3F

- 短答案：可以使用 HTTP 协议进行访问，返回 XML 或 JSON 格式数据的 API

- 再短一点：JSON over HTTP 或 XML over HTTP

- 特点：
    - 使用 HTTP 访问
    - 返回 JSON 或 XML 格式的纯数据
    - 使用 URL 描述资源
    - 使用不同的 HTTP 方法表示不同的操作

---

## 最简单的 Web API

code (app.py)
```python
from flask import Flask
app = Flask(__name__)

@app.route('/')
def hello_api():
    return {'message': 'Hello, PyCon China!'}
```

---

## 最简单的 Web API

code (app.py)
```python
from flask import Flask
app = Flask(__name__)

@app.route('/')
def hello_api():
*   return {'message': 'Hello, PyCon China!'}
```

test (with `pip install httpie`)
```bash
$ http http://localhost:5000
HTTP/1.0 200 OK
Content-Length: 30
Content-Type: application/json
Date: Tue, 17 Sep 2019 01:10:24 GMT
Server: Werkzeug/0.15.6 Python/3.6.8

{
    "message": "Hello, PyCon China!"
}
```

---

## 李辉 / Grey Li

- 独立 Web 开发者
- Flask 维护者之一
- 《Flask Web 开发实战》作者
- [HelloFlask](http://helloflaks.com) 管理员
- 个人网站 [greyli.com](http://greyli.com)

---

# 一个合格的 Python 程序员应该了解的事情

---
class: center, middle

# 👀 正确识认 Logo，从我做起

---
class: center, middle

---
class: center, middle

---
class: center, middle

# 重要的事情讲三遍

---
class: center, middle

#  👅  掌握正确的英语发音，从我做起

---

# Werkzeug

---
class: center, middle

# / (ˈvɛɐ̯kˌtsɔʏ̯k) / (than ke sao yi ke)

<br>

（发音来自作者本人）

---

# Jinja

---

# / (ˈdʒɪndʒə) / (jin ja)

<br>

---
class: center, middle

# Django

---

# 低压狗、低简狗、地张狗、地占狗、江狗？

---
class: center, middle

# [JANG-oh](https://docs.djangoproject.com/en/dev/faq/general/#what-does-django-mean-and-how-do-you-pronounce-it) (zhan go)

<br>

---

# 🧠 使用正确的术语，从我做起

---

# API / API 接口？

---

# 微服务？

---

# REST API / RESTful API？

---

# Web 服务？

---

# Web API ✔️

---
class: center, middle, inverse

# 什么样的 Web API 才是真正的 REST API？

---

## REST 架构的约束条件

- 客户端-服务器（Client-Server）
- 无状态（Stateless）
- 缓存（Cacheability）
- 分层系统（Layered System）
- 按需代码（Code-On-Demand，可选）
- 统一接口（Uniform Interface）
  - 请求中包含资源的 ID（Resource identification in requests）
  - 资源通过标识来操作（Resource manipulation through representations）
  - 消息的自我描述性（Self-descriptive messages）
  - 用超媒体驱动应用状态（Hypermedia as the engine of application state，HATEOAS）

---

# 基本没有完全符合 REST 要求的 API

---

# 不一定要完全遵守这些约束

---

![It's enough!](./images/enough.png)

---

## 使用名词表示资源

```bash
/token
    post
    delete
```

```bash
/login
    post

/logout
    post
```

whatever.

（正在面试除外） 🙄

```bash
/search
```

---

## 使用首部描述 API 版本

```http
Accept: application/vnd.example.v1+json
```

```http
Accept-version: v1
```

```bash
https://api.example.com/v1/
https://api-v1.example.com/
```

it depends.

but don't do this:
```bash
https://api.example.com/
https://new-api.example.com/
https://latest-api.example.com/
```

---

# 60% RESTful is ok 🤔

---

# 符合需求、易于实现、易于理解 > 符合标准

---

# 不一定非要使用扩展来实现 Web API

---

# 有一些 Flask 扩展很坑……

---

## 你以为的坑

---

## 实际的坑

---

## 甚至是这样的坑

---

## Flask Web API 扩展

- Flask-RESTful
- Flask-RESTPlus
- Flask-Restless
- Flask-API
- ……

---

# 避免引入不必要的复杂度

---
class: center, middle, inverse

# 试试使用 Flask 原生实现 Web API 吧

---

## 返回 jsonify() 和字典都可以

app
```python
flask flask import Flask # jsonify
app = Flask(__name__)
```

data
```python
data = {
    'en': 'Hello',
    'zh': '你好',
    'jp': 'kong ni ji wa'
}
```

return dict (new in 1.1)
```python
@app.route('/')
def hello_api():
    return data
    # return jsonify(data)
```

---

## 使用函数和类都可以

view function
```python
@app.route('/note/<int:id>', methods=['GET'])
def get_note(id):
    pass

@app.route('/note/<int:id>', methods=['DELETE'])
def delete_note(id):
    pass
```

class view
```python
from flask.views import MethodView

class Note(MethodView):

def get(self, note_id):
        pass

def delete(self, note_id):
        pass

app.add_url_rule('/notes/<int:note_id>', view_func=Note.as_view('note'), methods=['GET', 'DELETE'])
```

---

## 使用蓝本来组织 API 版本

```
apis/ # app package
  - v1
    - note.py
    - user.py
  - v2
    - note.py
    - user.py
  - __init__.py
  - models.py
  - decorators.py
  - auth.py
  - errors.py
```

```python
from apis.v1 import api_v1
from apis.v2 import api_v2

def create_app()
    app = Flask(__name__)
    app.register_blueprint(api_v1, url_prefix='api/v1/')
    app.register_blueprint(api_v2, url_prefix='api/v2/')
    return app
```

---

## 错误处理

```python
from flask import jsonify
from werkzeug.http import HTTP_STATUS_CODES

def api_abort(code, message=None, **kwargs):
    if message is None:
        message = HTTP_STATUS_CODES.get(code, 'Error')

response = jsonify(code=code, message=message, **kwargs)
    response.status_code = code
    return response  # You can also just return (response, code) tuple
```

- 用于主动返回错误响应
- 从 Werkzeug 获取 HTTP 错误的状态码作为错误描述
- 可以自定义错误消息和附加其他数据

---

## 错误处理

```python
from flask import jsonify
from werkzeug.http import HTTP_STATUS_CODES

def api_abort(code, message=None, **kwargs):
    if message is None:
*       message = HTTP_STATUS_CODES.get(code, 'Error')

response = jsonify(code=code, message=message, **kwargs)
    response.status_code = code
    return response  # You can also just return (response, code) tuple
```

- 用于主动返回错误响应
- 从 Werkzeug 获取 HTTP 错误的状态码作为错误描述
- 可以自定义错误消息和附加其他数据

---

## 错误处理

usage 1

```python
if g.current_user != item.author:
    return api_abort(403)
```

usage 2

```python
if user is None or not user.validate_password(password):
    return api_abort(code=400, message='Either the username or password was invalid.')
```

---

## 错误处理

usage 3

```python
@app.errorhandler(404)
def page_not_found(e):
    return api_abort(404)

@app.errorhandler(405)
def method_not_allowed(e):
    return api_abort(405)

@app.errorhandler(500)
def internal_server_error(e):
    return api_abort(500)
```

---

## JSON 数据封装

```python
def note_schema(note):
    return {
        'id': note.id,
        'self': url_for('.note', note_id=note.id, _external=True),
        'kind': 'Note',
        'body': note.body,
        'author': {
            'id': 1,
            'url': url_for('.user', _external=True),
            'username': note.author.username,
            'kind': 'User',
        },
    }
```

- 把模型类数据序列化（serialize）成 JSON 数据
- 你也可以把这个函数作为方法放到模型类里
- 使用 url_for() 生成 URL

---

## JSON 数据封装

```python
class NoteAPI(MethodView):
    decorators = [auth_required]

def get(self, note_id):
        """Get note."""
        note = Note.query.get_or_404(note_id)
        if g.current_user != item.author:
            return api_abort(403)
*       return note_schema(note)
```

---

## 分页

```python
def notes_schema(notes, current, prev, next, pagination):
    return {
        'self': current,
        'kind': 'NoteCollection',
        'notes': [note_schema(note) for note in notes],
        'prev': prev,
        'last': url_for('.notes', page=pagination.pages, _external=True),
        'first': url_for('.notes', page=1, _external=True),
        'next': next,
        'count': pagination.total
    }
```

---

## 分页

```python
class NotesAPI(MethodView):
    decorators = [auth_required]

def get(self):
        """Get current user's all items."""
        page = request.args.get('page', 1, type=int)
        per_page = request.args.get('per_page', 10, type=int)
        if per_page > 10:
            per_page = current_app.config['NOTE_PER_PAGE']
        pagination = Note.query.with_parent(g.current_user).paginate(page, per_page)
        notes = pagination.items
        current = url_for('.notes', page=page, _external=True)
        prev = None
        if pagination.has_prev:
            prev = url_for('.notes', page=page - 1, _external=True)
        next = None
        if pagination.has_next:
            next = url_for('.notes', page=page + 1, _external=True)
*       return notes_schema(notes, current, prev, next, pagination)
```

---

## 请求解析

validate
```python
def validate_note(json):
    body = json.get('body')
    if body is None or str(body).strip() == '':
        raise ValidationError('The note body was empty or invalid.')
    return Note(body=body, author=g.current_user)
```

error
```python
class ValidationError(ValueError):
    pass

@app.errorhandler(ValidationError)
def validation_error(e):
    return api_abort(400, e.args[0])
```

---

## 请求解析

```python
class NotesAPI(MethodView):
    decorators = [auth_required]

def post(self):
        """Create new note."""
*       note = validate_note(request.get_json())
        db.session.add(note)
        db.session.commit()
        response = jsonify(note_schema(note))
        response.status_code = 201
        response.headers['Location'] = url_for('.note', note_id=note.id, _external=True)
        return response
```

---

## 身份认证

```python
class AuthTokenAPI(MethodView):

def post(self):
        grant_type = request.form.get('grant_type')
        username = request.form.get('username')
        password = request.form.get('password')

# validate grant_type, username and password

token, expiration = generate_token(user)

response = jsonify({
            'access_token': token,
            'token_type': 'Bearer',
            'expires_in': expiration
        })
        response.headers['Cache-Control'] = 'no-store'
        response.headers['Pragma'] = 'no-cache'
        return response

api_v1.add_url_rule('/oauth/token', view_func=AuthTokenAPI.as_view('token'), methods=['POST'])
```

---

## 身份认证

```python
from flask import g, current_app, request
from itsdangerous import TimedJSONWebSignatureSerializer as Serializer, BadSignature, SignatureExpired

def generate_token(user):
    expiration = 3600
    s = Serializer(current_app.config['SECRET_KEY'], expires_in=expiration)
    token = s.dumps({'id': user.id}).decode('ascii')
    return token, expiration

def validate_token(token):
    s = Serializer(current_app.config['SECRET_KEY'])
    try:
        data = s.loads(token)
    except (BadSignature, SignatureExpired):
        return False
    user = User.query.get(data['id'])
    if user is None:
        return False
    g.current_user = user
    return True
```

---

## 身份认证

```python
from functools import wraps

def auth_required(f):
    @wraps(f)
    def decorated(*args, **kwargs):
        token_type, token = get_token()

if request.method != 'OPTIONS':
            if token_type is None or token_type.lower() != 'bearer':
                return api_abort(400, 'The token type must be bearer.')
            if token is None:
                return token_missing()
            if not validate_token(token):
                return invalid_token()
        return f(*args, **kwargs)

return decorated
```

---

## 身份认证

```python
def get_token():
    if 'Authorization' in request.headers:
        try:
            token_type, token = request.headers['Authorization'].split(None, 1)
        except ValueError:
            token_type = token = None
    else:
        token_type = token = None

return token_type, token
```

---

## 身份认证

```python
def invalid_token():
    response = api_abort(401, error='invalid_token', error_description='Either the token was expired or invalid.')
    response.headers['WWW-Authenticate'] = 'Bearer'
    return response

def token_missing():
    response = api_abort(401)
    response.headers['WWW-Authenticate'] = 'Bearer'
    return response
```

---

## 其他选择

- Django REST Framework
- API Star
- Starlette
- Hug
- FastAPI
- Falcon
- Eve (based on Flask)
- Connexion (based on Flask)
- ……

---

# 谢谢

---

# 插播一条广告

- 时间：下午 4:40

- 地点：就在这个会场

- 事件：闪电演讲

- 人物：等你

---

## Links & Contact

- website: [greyli.com](http://greyli.com)
- code: [github.com/greyli/noteapi](https://github.com/greyli/noteapi)
- slides: [github.com/greyli/pyconchina2019-api](https://github.com/greyli/pyconchina2019-api)
